Series 6800 Flexible Strut Joints & Vibrasnubs

Series 6800 Flexible Strut Joints & Vibrasnubs

Information at a Glance

Series

Series 6800 Flexible Strut Joints & Vibrasnubs

Material

Steel

Size

1/2 -48 in. / 12-1200 mm

Pressure

≤100, 150 & 300 PSI / 3, 10 & 20 Bar

Motion

unlimited

Canadian Registration



This product is registered throughout Canada under
CRN 0D9278.59870YTNADD3

Other Products

Product Description

When used in tandem, Hyspan Barco “Ball Type” Flexible Strut Joints provide a rigid structural support capable of resisting high tensile and compressive loads while allowing lateral, angular and rotation movement. The precision ball and socket construction provides a maintenance free rigid connection to brace piping, pressure vessels, boilers, tanks and other process equipment.

Strut Joints combined with Hyspan Barco Vibrasnub hydraulic vibration snubbers form an assembly that absorbs tensile and compressive shock and vibration loads while allowing gradual movements such a thermal growth. Unlike comparable products, Vibrasnub vibration snubbers are totally self-contained with no external tubing or components providing a low maintenance compact design.

Catalog 3000B includes complete design information for flexible strut joints and Vibrasnubs including force, amplitude charts.
