Series 2500 Low Pressure Round And Rectangular Expansion Joints
Information at a Glance
Series
2500 Low Pressure Round & Rectangular Bellows Expansion Joints
Material
Steel
Size
4-240 in. / 100-6000 mm
Rectangle Unlimited
Pressure
≤150 & 300 PSI / 10 & 20 Bar
≤1 5/ 1 Bar
Motion
16+ in. / 400+ mm
3+ in. / 75+ mm
Canadian Registration
This product is registered throughout Canada under
CRN 0D9278.59870YTNADD3
1-Year Warranty
Other Products
Series 9500 Alignment GuidesProduct Description
Series 2500 expansion joints have been specifically designed for round and rectangular low pressure duct and piping applications. Applications such as diesel engine exhaust, gas turbine exhaust, ventilation ducting, and boiler exhaust ducting. The designs are highly flexible, and a variety of materials are available for high temperatures or corrosive applications. Specifications vary for each product group but in general Series 2500 round expansion joints are designed for pressures ranging from full vacuum to 15 psig. High-pressure round expansion joints for turbocharged applications are available.
Series Products
Series 2504-2507 1-Ply Bellows Joint
Series 2504-2507 Round Single Ply joints are highly flexible. Service is for thermal motions in pipe or duct systems. Standard sizes range from 6″ through 48”. Hyspan has the capability to manufacture expansion joints with diameters up to 20 feet. Standard end connections are fixed flange, floating flange, angle flange, and weld end. Options are available with stainless steel wetted surfaces or all stainless-steel construction for elevated or cryogenic temperatures and corrosion resistance.
Series 2509-2511 Round Laminated Bellows Expansion Joints
Series 2509-2511 Round Laminated Bellows Expansion Joints include 3 plies for maximum flexibility or internal vibration dampening. Service is for extreme axial motions or direct installation on vibrating equipment such as engine exhaust manifolds, turbochargers, and fan connections. Sizes range from 3″ and larger pipe and tube sizes, with standard fixed or floating flanges, and weld end connections. Hyspan has the capability to manufacture expansion joints with diameters up to 20 feet. Options are available with stainless steel wetted surfaces or all stainless steel construction for elevated or cryogenic temperatures and corrosion resistance.
Series 25RECT Rectangular Expansion Joints
Series 25RECT Rectangular Expansion Joints are fabricated to customer specified dimensions with standard Hyspan convolution profiles or specialty designs. A variety of corner configurations are available. Materials of construction range from carbon steel to stainless steel and high nickel alloy steels. Metal rectangular expansion joints are leak tight and may last 15 years or more.
Series 2554-2555 Hyseal
Series 2554-2555 Hyseal support pipe penetration through a containment wall or bulkhead. Three catalog motion ratings are available, with two end configurations, and multiple shroud options. Clam shell replacements are available. Engineered solutions to existing applications are also available. Consult Hyspan for support for Hyseals.
Custom Assemblies
Series 2500 engineered bellows are commonly incorporated into assemblies designed specifically for a customer’s application. Unique fittings, vibration, high-flow velocity, high-temperature, cryogenic temperature, and corrosion resistance can all be considered in product design. Hyspan’s total capability to design products and fabricate component parts minimizes development time and provides control over production. Cycle life and vibration testing are available.
Ordering Information
Hyspan products are available from Sales Representatives and Distributors, or they can be purchased direct from the factory. The minimum factory order for open account customers, COD shipments, or bank card sales is $100.00 (USD). All major credit or debit cards are accepted. The minimum order for new account applicants is $100.00. Our Confidential Credit Application can be downloaded and forwarded to Hyspan for processing. All orders are subject to the following Terms and Conditions, and the above warranty applies to all material. Please read these documents.
