4501V-4508V V-Flex Seismic Connector

4501V-4508V V-Flex Seismic Connector

Information at a Glance

Series

4500 Braided Hose Connectors

Material

Steel

Size

1/2 – 32 in. / 12 – 800 mm

Pressure

150 PSI / 10 Bar

Canadian Registration



This product is registered throughout Canada under
CRN 0D9278.59870YTNADD3

Other Products

Product Description

4501-4505 Straight Braided Hose Connectors

Series 4500 V-Flex Connectors are designed to absorb thermal expansion or contraction, or for seismic isolation of steel pipe or copper tube installations. The braided metal hose elements that are incorporated into the design offer benefits that are not available in other products that are used for these applications, and the unique Hyspan “V” configuration provides advantages over other metal hose connectors.

  • Anchor forces are minimized because the pressure thrust is reacted by the wire braid.
  • Anchor forces are minimized because of the inherent high flexibility of the metal hose.
  • The “V” configuration allows adjacent piping to be nested to save space.
  • V-Flex connectors can absorb in-plane extension and compression, or out of plane lateral offset.

    • Technology & Advantages

    V-Flex connectors can be installed in vertical or horizontal pipe or tube runs as illustrated. The installation must be anchored and properly guided adjacent to the connector and throughout the run. Intermediate guide spacing is given in Tables 1 & 2 below. Refer to Hyspan Series 9500 alignment guides for details on available guides. The Intermediate Anchor must be designed to react a force equal to the connector spring force (Column 3 of Tables 3 & 4). This force is primarily the result of the stiffness of the connector caused by the internal pressure. If the system pressure is less than the 150 psig used for the tabulation, this force can be reduced proportionately.

    Common Applications

    Series 4500 V-Flex Connectors are available as standard products for 1/2″ through 4″ nominal pipe size with stainless steel braided hose and steel fittings – flanged, weld end or grooved. Copper tube end configurations with bronze hose and braid are available 1/2″ through 3″ nominal size with female sweat ends or grooved ends. Design conditions are 150 psig and 500ºF with a choice of 2″, 3″ or 4″ of travel.

    Thermal Expansion Applications

    V-Flex connectors can be installed in vertical or horizontal pipe or tube runs as illustrated. The installation must be anchored and properly guided adjacent to the connector and throughout the run. Intermediate guide spacing is given in Tables 1 & 2 below. Refer to Hyspan Series 9500 alignment guides for details on available guides. The Intermediate Anchor must be designed to react a force equal to the connector spring force (Column 3 of Tables 3 & 4). This force is primarily the result of the stiffness of the connector caused by the internal pressure. If the system pressure is less than the 150 psig used for the tabulation, this force can be reduced proportionately.

    V-Flex Connector Installed in the Middle of a Run

    V-Flex Connector Installed Adjacent to an Anchor

    Seismic Applications

    V-Flex connectors installed for seismic separation require an Intermediate Anchor on each side if the separation that is no greater than the overall length of the V-Flex (Tables 3 & 4) plus four pipe diameters on each side. If the separation is greater, an alignment guide (Series 9500) must be installed within four pipe diameters from the V-Flex. The Intermediate Anchor must be designed to react a force equal to the connector spring force (Column 3 of Tables 3 & 4). This force is primarily the result of the stiffness of the connector caused by the internal pressure. If the system pressure is less than the 150 psig used for the tabulation, this force can be reduced proportionately.

    Table 1: V-Flex Steel Pipe Connectors

    Nominal
    Size
    (NPS)    		 Part Number
    4501,4504
    4505,4508    		 Guide
    Spacing
    (Feet)    		 Nominal
    Size
    (NPS)    		 Part Number
    4501,4504
    4505,4508    		 Guide
    Spacing
    (Feet)
    1/2 -V11-2
    -V11-3
    -V11-4    		 14 2 -V31-2
    -V31-3
    -V31-4    		 67
    3/4 -V14-2
    -V14-3
    -V14-4    		 20 2 1/2 -V35-2
    -V35-3
    -V35-4    		 98
    1 -V19-2
    -V19-3
    -V19-4    		 29 3 -V40-2
    -V40-3
    -V40-4    		 132
    1 1/4 -V24-2
    -V24-3
    -V24-4    		 39 4 -V48-2
    -V48-3
    -V48-4    		 178
    1 1/2 -V27-2
    -V27-3
    -V27-4    		 48
    1 2 3 4 5 6

    Table 2: V-Flex Copper Tube Connectors

    Copper
    Tube
    Size    		 Part
    Number
    4507,4509    		 Guide
    Spacing
    (Feet)    		 Copper
    Tube
    Size    		 Part
    Number
    4507,4509    		 Guide
    Spacing
    (Feet)
    1/2 -V08-2
    -V08-3
    -V08-4    		 5 1 1/2 -V23-2
    -V23-3
    -V23-4    		 20
    3/4 -V12-2
    -V12-3
    -V12-4    		 8 2 -V29-2
    -V29-3
    -V29-4    		 31
    1 -V16-2
    -V16-3
    -V16-4    		 12 2 1/2 -V33-2
    -V33-3
    -V33-4    		 45
    1 1/4 -V20-2
    -V20-3
    -V20-4    		 15 3 -V37-2
    -V37-3
    -V37-4    		 59
    1 2 3 4 5 6

    Note: The alignment guide spacing tabulated in Tables 1 & 2 was calculated in accordance with the recommendations of the Standards of the Expansion Joint Manufacturers Association solely on the basis of the V-Flex spring force. Alignment guides do not provide support for the weight of the system, and it may be necessary to install additional guides for long flexible runs to ensure alignment.

    Standard Designs

    Materials of Construction

    Hose & Braid: Type 321 S/S hose, type 304 S/S braid

    Flanges: Plate or forged carbon steel.

    Elbows: ASTM A234 carbon steel, long radius

    Table 3: Design Pressure 150 psig Test Pressure 225 psig Design Temperature 500ºF

      P/N 4501 Flanged P/N 4504 Welded P/N 4505 Threaded P/N 4508 Grooved
    Nominal
    Size
    (NPS)    		 Part Number
    4501, 4504
    4505, 4508    		 Spring
    Force
    (lbs.)    		 Height
    (inches)    		 Overall
    Length
    (inches)    		 Weight
    (lbs.)    		 Overall
    Length
    (inches)    		 Weight
    (lbs.)    		 Overall
    Length
    (inches)    		 Weight
    (lbs.)    		 Overall
    Length
    (inches)    		 Weight
    (lbs.)
    1/2 -V11-2
    -V11-3
    -V11-4    		 31
    36
    40    		 9.69
    11.38
    12.88    		     21.00
    24.38
    27.38    		 1
    1
    1    		 26.00
    29.38
    32.38    		 2
    2
    2
    3/4 -V14-2
    -V14-3
    -V14-4    		 33
    37
    42    		 9.94
    11.81
    13.38    		     20.69
    24.44
    27.56    		 2
    2
    2    		 25.69
    29.44
    32.56    		 2
    3
    3    		 20.69
    24.44
    27.56    		 2
    2
    2
    1 -V19-2
    -V19-3
    -V19-4    		 37
    42
    47    		 10.81
    12.75
    14.44    		     22.81
    26.69
    30.06    		 3
    3
    3    		 27.81
    31.69
    35.06    		 3
    4
    4    		 22.81
    26.69
    30.06    		 3
    3
    3
    1 1/4 -V24-2
    -V24-3
    -V24-4    		 46
    52
    59    		 12.50
    14.63
    16.44    		     26.50
    30.75
    34.44    		 4
    5
    5    		 31.50
    35.75
    39.44    		 5
    6
    6    		 26.50
    30.75
    34.44    		 4
    5
    5
    1 1/2 -V27-2
    -V27-3
    -V27-4    		 48
    56
    63    		 13.25
    15.44
    17.31    		     28.31
    32.69
    36.44    		 6
    7
    7    		 35.31
    37.69
    41.44    		 7
    8
    9    		 28.31
    32.69
    36.44    		 6
    7
    7
    2 -V31-2
    -V31-3
    -V31-4    		 54
    62
    70    		 15.06
    17.50
    19.63    		 33.25
    38.13
    42.38    		 20
    22
    23    		 32.75
    37.63
    41.88    		 10
    11
    12    		 37.69
    42.63
    46.88    		 12
    13
    14    		 32.75
    37.63
    41.88    		 10
    11
    12
    2 1/2 -V35-2
    -V35-3
    -V35-4    		 57
    66
    74    		 16.88
    19.50
    21.81    		 37.56
    42.88
    47.50    		 31
    33
    34    		 36.94
    42.25
    46.88    		 17
    19
    20    		 43.69
    49.00
    53.63    		 20
    22
    24    		 36.94
    42.25
    46.88    		 17
    19
    20
    3 -V40-2
    -V40-3
    -V40-4    		 62
    72
    81    		 18.81
    21.81
    24.25    		 42.19
    48.19
    53.13    		 39
    41
    42    		 41.56
    47.56
    52.50    		 23
    25
    27    		 48.31
    54.31
    59.25    		 27
    28
    31    		 41.56
    47.56
    52.50    		 23
    25
    27
    4 -V48-2
    -V48-3
    -V48-4    		 83
    95
    107    		 20.69
    23.88
    26.56    		 47.50
    53.81
    59.13    		 61
    64
    67    		 46.88
    53.19
    58.50    		 40
    43
    45    		 53.63
    59.69
    65.25    		 46
    49
    51    		 46.88
    53.19
    58.50    		 40
    43
    45
    1 2 3 4 5 6 7 8 9 10 11 12
    Note: (1) The Dash Number in Column 2 indicates the maximum rated travel - dash 2 is 2" axial extension, axial compression or lateral offset.
    (2) The Spring Force in Column 3 is the force to displace the connector the rated travel at 150 psig.

    Materials of Construction

    Hose & Braid: Type C505 bronze hose with bronze braid.

    Elbows & Tube: ASTM B88 with sweat connections per ASME B16.22

    Table 4: Design Pressure 150 psig Test Pressure 225 psig Design Temperature 500ºF

      P/N 4507 Sweat P/N 4509 Grooved
    Copper
    Tube
    Size    		 Part Number
    4507
    4509    		 Spring
    Force
    (lbs.)    		 Height
    (inches)    		 Overall
    Length
    (inches)    		 Weight
    (lbs.)    		 Overall
    Length
    (inches)    		 Weight
    (lbs.)
    1/2 -V08-2
    -V08-3
    -V08-4    		 29
    33
    37    		 10.25
    11.81
    13.38    		 22.06
    25.56
    28.63    		 1
    1
    1    		 39.94
    45.25
    49.88    		 9
    11
    12
    3/4 -V12-2
    -V12-3
    -V12-4    		 31
    34
    39    		 12.00
    13.75
    15.50    		 25.75
    29.88
    33.38    		 2
    2
    3    		 41.25
    47.63
    52.50    		 12
    13
    15
    1 -V16-2
    -V16-3
    -V16-4    		 34
    39
    44    		 12.63
    14.75
    16.63    		 28.00
    32.25
    36.00    		 3
    3
    4    		 45.13
    51.50
    56.75    		 16
    18
    20
    1 1/4 -V20-2
    -V20-3
    -V20-4    		 43
    48
    55    		 14.44
    16.75
    18.75    		 32.19
    36.75
    40.88    		 4
    5
    5
    1 1/2 -V23-2
    -V23-3
    -V23-4    		 45
    52
    58    		 15.19
    17.56
    19.63    		 34.50
    39.25
    43.25    		 6
    7
    7
    2 -V29-2
    -V29-3
    -V29-4    		 50
    58
    65    		 17.63
    20.25
    22.63    		 39.94
    45.25
    49.88    		 9
    11
    12
    2 1/2 -V33-2
    -V33-3
    -V33-4    		 53
    61
    69    		 18.31
    21.50
    24.00    		 41.25
    47.63
    52.50    		 12
    13
    15
    3 -V37-2
    -V37-3
    -V37-4    		 58
    67
    75    		 19.88
    23.00
    25.63    		 45.13
    51.50
    56.75    		 16
    18
    20
    1 2 3 4 5 6 7 8

    Note:
    (1) The Dash Number in Column 2 indicates the maximum rated travel – dash 2 is 2″ axial extension, axial compression or lateral offset.
    (2) The Spring Force in Column 3 is the force to displace the connector the rated travel at 150 psig.

    Installation Procedure

    Application: V-Flex Connectors are designed to absorb thermal or seismic movements as axial motion (direction of pipe or tube centerline) or lateral motion in all planes (perpendicular to the pipe or tube centerline).

    Operating Conditions: All V-Flex connectors are designed for 150 psig at 500ºF, and factory tested to 225 psig. Standard connectors are designed for 2″, 3″ or 4″ of axial extension or compression, and 2″, 3″ or 4″ of lateral offset in any plane. Be certain that the system requirements do not exceed the design travel for the connector to be installed.

    Guides, Supports, Anchors: V-Flex connectors require anchors, guides and supports. Refer to Thermal Expansion Applications (links to Thermal Expansion Applications in V-Flex Text) or Seismic Applications (links to Seismic Applications in V-Flex Text) for the guide and anchor requirements. It may be necessary to support the center elbow of the connector- refer to the illustrations of horizontal and vertical installations.

    Flow Direction: The flow can be in either direction.

    Shipping Restraints: V-Flex connectors are normally not supplied with shipping restraints. Be certain that the connector is installed
    at the neutral length unless otherwise specified. Refer to the tabulated data,
    Tables 3 & 4, for the correct length

    Welding, Brazing & Soldering: V-Flex Connectors must be protected from welding arc strikes, sparks, slag, flux and other debris resulting from the installation of the connector or other activity in the vicinity. Model 4507 requires brazing or soldering for installation. Do not exceed a temperature of 1000ºF and be certain the flux or acid is neutralized.

    POST INSTALLATION INSPECTION:

    • Inspect the connector for damage with special attention to the wire braid.
    • Is the connector at the correct location as specified?
    • Are the anchors and guides correctly installed? Are the guides free to move?
    • Confirm that the connector length is correct.
    • Is the center elbow of the connector supported – if required
